1200*12000China Rotary Dryer Manufacturer Rotary Dryer from China manufacturer - Zhengzhou Dehong Machine Manufacturing Co., Ltd

1200*12000China Rotary Dryer Manufacturer Rotary Dryer

Place of Origin:

Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 1200*12000

Packing: Customer requirements

Brand Name: Dehong

Warranty: one year

Production Capacity: 100pieces

Delivery Date: According to the contract w...

Type: drying equipment

certification: ISO 9001:2008

Type: tumble dryer Use: drying Certification: ISO Place of Origin: Henan China (Mainland) Brand Name: DeHong Condition: New warranty: one year

Introduction to 1200*12000 China leading Rotary Dryer :

Rotary dryer is suitable to dry metallic and mineral, clay in cement industry and coal in coal mine, etc. rotary dryer can be widely used to dry various materials, and is simple to be operated.

Working principle of 1200*12000 China leading Rotary Dryer :

Materials are sent to hopper of rotary dryer by belt conveyor or bucket elevator. The barrel is installed with slope to horizontal line. Materials enter the barrel from the higher side, and hot air enters the barrel from lower side, materials and hot air mix together. Materials go to the lower side by gravity when the barrel rotates. Lifters on the inner side of barrel lift materials up and down to make materials and hot air mix completely. So drying efficiency is improved.

Features of 1200*12000 China leading Rotary Dryer:

1. The machine's design is reasonable, have reliable performance, high efficiency, dry and heat uniform, maintenance convenient.

2. Equipment adopts self-aligning type tug structure, the tug and with good tire-roller, greatly reduces the wear and tear of power consumption.

3. Resistance to overload ability, cylinder smooth operation and high reliability.

4. Drying machine has the characteristics of high temperature resistant, high temperature hot air can be used for a rapid drying of material.

5. Drum dryer processing capacity, fuel consumption, dry low cost less.

Technical parameter of 1200*12000 China leading Rotary Dryer:

Type (mm)	Gradient (°)	rotation speed(r/min)	input temperature (ºC)	motor power (kw)	output(t/h)	Weight (t)
Φ600×6000	3-5	3-8	≤700	3	0.5-1.5	2.9
Φ800×8000	3-5	3-8	≤700	4	0.8-2.0	3.5
Φ800×10000	3-5	3-8	≤700	4	0.8-2.5	4.5
Φ1000×10000	3-5	3-8	≤700	5.5	1.0-3.5	5.6
Φ1200×10000	3-5	3-8	≤700	7.5	1.8-5	14.5
Φ1200×12000	3-5	3-8	≤700	11	2-6	14.8
Φ1500×12000	3-5	2-6	≤800	15	3.5-9	17.8
Φ1800×12000	3-5	2-6	≤800	18	5-12	25
Φ2200×12000	3-5	1.5-6	≤800	18.5	6-15	33
Φ2200×18000	3-5	1.5-6	≤800	22	10-18	53.8
Φ2200×20000	3-5	1.5-6	≤800	30	12-20	56
Φ2400×20000	3-5	1.5-5	≤800	37	18-30	60
Φ2800×15000	3-5	1.5-5	≤800	40	20-35	72.5
Φ2800×18000	3-5	1.5-5	≤800	40	25-35	75
Φ3000×20000	3-5	1.5-5	≤800	55	28-40	78
Φ3000×25000	3-5	1.5-5	≤800	75	32-45	104.9
