Chinese drum dryer dryer manufacturing from China manufacturer - Zhengzhou Dehong Machine Manufacturing Co., Ltd

Payment Terms:	T/T
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean,Land

Delivery Date: According to the contract w...

Machine type: dryer

Warranty: one year

Packing: Customer requirements

Brand Name: Dehong

Certification: ISO 9001:2008

Place of Origin: Henan China (Mainland) Brand Name: DeHong
Type: Drum Drying Equipment certificate: ISO9001 Delivery Detail: 10-15 working days

Specifications of three drum dryer:

1.High output, low energy consumption
2.Easy operation
3.Reasonable structure
4.Perfect in workmanship

Three drum dryer application:

Three drumdryer used to drying humidity particle materials, such as yellow sandused by industry, variety of snad which used in foundry industry, blastfurnace slag which used in cement industry of buildingmaterials,chemical, food, compound fertilizer,copra,etc. Small particlesize aclay. According to requirments of the water in the products afterdryer. The water content 1-0.5% or less can be achieved after process.

Three drum rotary dryer features:

The rotary dryer shell is self-insulation, thermal efficiency up to 80%(single drum dryer is only 35), the production increase 100%.
The whole shell length is shorter than the single drum 60%, it is good for the technology layout, reduce the factory area, and reduce the foundation investment.

The three drum rotary dryer is high efficiency, outside of the cylinder is 60 degree, the discharging temperature is lower than 60 degree. The outlet temperature is low, ehich can increase the dust collector equipment llife.

Main technical parameter of three drum rotary dryer:

Model Specification	Capacity (t/h)				Coal consumption (kg/t) dry material	Power kw
Model Specification	slag	Coal ash	clay	sand	Coal consumption (kg/t) dry material	Power kw
DH2.0x4	5-10	4	4-7	10-15	12-14	11
DH2.0x4.5	12-18	6	7-10	15-25	12-14	11
DH2.5x5	20-30	10	10-15	25-35	10-12	15
DH2.5x6	30-35	15	15-20	35-45	10-12	15
DH3.0x6	35-40	20	20-23	45-55	8-10	23
DH3.0x7	40-45	25	23-25	55-65	8-10	23
DH3.2x7	45-50	30	25-30	65-75	6-8	30
DH3.2x8	50-60	35	30-35	75-85	6-8	30
DH3.6x8	60-70	40	35-40	85-95	6-8	46
